- ระดับความดังเสียงสูงสุด 90 dB ที่ระยะ 1 เมตร เหมาะสำหรับโรงงานที่มีเสียงรบกวนสูง
- มีเสียงให้เลือกใช้งานได้ 32 เสียงเหมาะสำหรับการใช้งานหลากหลายรูปแบบ
- มี Rotary switch ด้านหน้าสำหรับปรับความดังและเลือก Group เสียงได้ง่ายหลังจากการติดตั้งแล้ว
- เลือก Group เสียงได้ A ถึง P เพื่อเล่นเสียงตามที่ต้องการ (4 pre-recorded sound)
- สามารถสร้าง Group เสียงใหม่เพื่อเลือกเสียงที่ต้องการจาก Group เสียงอื่นๆทั้ง 32 เสียง ด้วย SD card (Sold separately)
- ได้รับมาตรฐาน RoHS
※ PATLITE Corporation ไม่ได้รับอนุญาติให้ใช้งานเสียงที่ได้รับลิขสิทธิ์ในรุ่น BD-A , BD-C และ BD-D ภายนอกพื้นที่ของประเทศญี่ปุ่น กรุณาติดต่อตัวแทนของ PATLITE เพื่อสอบถามข้อมูลเพิ่มเติม
DIMENSIONS | - 80mm square (front) - 67.5mm square (back) |
---|---|
RATED VOLTAGE | - DC 12-24V - AC100V/220V |
AUDIBLE STYLE | - Alarms / Chimes / Melodies - Pre-installed |
MOUNTING | - Upright position - Indoors only |
BODY COLOR | - Light Gray - Dark Gray |
VOLUME | - Maximum 90dB at 1 meter - Volume adjustable from zero |
SOUND STORAGE | - A total of 32 sounds stored (See Specifications for list) - Arranged in 8 selectable groups of sounds - Each group has 4 pre-arranged sounds |
CHANNEL SELECTION | - Select one of 8 sound groups by rotary switch - Select any of 4 sounds in chosen groups by signal input - Re-program last sound group from sounds stored in the unit (optional sound card required) |
SOUND CHART | - Open the BD-E Specifications page for the complete list of sounds installed - Only the BD-E sounds are available for replay in the "Sound Samples" link above |
CONFORMITY STANDARDS | - CE Marking - UL Component Recognition (US) - c-UL Component Recognition (Canada) - RoHS |
PROTECTION RATINGS | - IP-54 (panel-mounted, front direction only) |
REMARKS | - Dry contact closure such as switches or relay contacts - Open-collector transistor (NPN) |
FUNCTIONS | - Sound only plays during contact closure - Sound stops when contact is Open |
OPTIONS | - SD Card |
